DEEPCOOL
DeepCool PM750D 750W PSU, 120mm Silent High Performance Fan, 80 PLUS Gold, Non Modular, UK Plug, Flat Black Cables, Japanese Bulk Capacitors
DeepCool PM750D 750W PSU, 120mm Silent High Performance Fan, 80 PLUS Gold, Non Modular, UK Plug, Flat Black Cables, Japanese Bulk Capacitors
PM750D
Reliable 80 PLUS Gold Efficiency
DeepCool PM750D Series non-modular power supplies are certified 80 PLUS Gold for efficient power delivery with great performance at a great value.
80 PLUS GOLD CERTIFIED
Guarantees a minimum efficiency of 90% or higher under typical loads for reliable power delivery with little waste.
QUALITY TOPOLOGY
For solid power performance and minimal signal noise, the PM-D series PSU features a full-bridge LLC topology with DC-DC conversion and Japanese bulk capacitors that delivers terrific reliability.
BUILT TO SPEC
Made to meet modern power supply design standards for consistent voltage stability, each PM-D power supply is also compliant with Intel PSU guidelines that support instant-on power from sleep or standby modes.
80 PLUS Gold
80 PLUS Gold certified - Up to 87~90% efficient (20~100% Loading)
Silent and High Performance Fan
120mm silent fan has temperature control function to keep low noise
ENOUGH POWER TO GO AROUND
The PM750D features three independent PCIe outputs and two EPS connectors for continuous high quality power that supports the latest high-end graphics cards and motherboards for gaming excellence.
EFFICIENCY THROUGHOUT
The PM-D series power supplies are compliant with the 2014 ErP regulations on energy savings and also the IEC 62368-1 for safety standards.
PEACE OF MIND
Safeguard your power source with well-round circuit protection including OPP/OVP/SCP/OTP/OCP.
Model
R-PM750D-FA0B-UK
Type
ATX 12V V2.4
Wattage
750W
Input Voltage
100-240V
Fan Size
120mm Hydro Bearing
Topology
Active PFC + Full Bridge SRC LLC + DC to DC
Capacitors
Japanese Bulk Capacitor
Power Good Signal
100-150ms
Hold Up Time
>16ms (75% Load)
Efficiency
>90% Under Typical Load (50% Loading)
Standby Efficiency
ErP Lot 3 2014
Certification
80 PLUS Gold
Protection
OPP / OVP / SCP / OTP / OCP
Operation Temperature
0~40°C
Regulatory
TUV / cTUVus / CCC / CE / FCC / UKCA / EAC / BIS
MTBF
100,000 Hours
Connections
1 x Motherboard 24-pin
2 x EPS 12V Connector 8 (4+4) Pin
3 x PCI-E (6+2 pin)
6 x SATA
3 x Peripheral (Molex 4-pin)
Product Dimension ( W x L x H )
150 x 140 x 86mm
Master Carton Quantity
6
